Standard
Design conforms to BS 7211
Fire protection standards
|
Line integrity
|
IEC 60331-21; BS 6387 CWZ; DIN VDE 0472- 814(FE180); BS 8434-2 (120mins); BS 5839-1 Clause 26 2e;CEI 20-36/2-1; SS229-1; NBN C 30-004 (cat. F3); NF C32-070-2.3(CR1
|
|
Circuit Integrity Under Mechanical Shock
|
EN 50200(PH120); CEI 20-36/4-0
|
|
Circuit integrity under mechanical impact and water jet application
|
EN 50200 Appendix E
|
|
System Circuit Integrity
|
Depending on the laying system DIN 4102-12, E30
|
|
Flammability (Single Vertical Wire Test)
|
EN 60332-1-2; IEC 60332-1-2; BS EN 60332-1-2; VDE 0482-332-1 ; NBN C 30-004 (cat. F1);NF C32-070-2.1(C2); CEI 20-35/1-2; EN 50265-2-1*; DIN VDE 0482-265-2-1*
|
|
Reduce fire spread (vertical installation of cable bundles test)
|
EN 60332-3-24 (cat. C); IEC 60332-3-24; BS EN 60332-3-24; VDE 0482-332-3;NBN C 30-004 (cat. F2); NF C32-070-2.2(C1); CEI 20-22/3-4; EN 50266-2-4*;DIN VDE 0482-266-2-4
|
|
Halogen-free
|
IEC 60754-1; EN 50267-2-1; DIN VDE 0482-267-2-1; CEI 20-37/2-1 ; BS 6425-1*
|
|
No emission of corrosive gases
|
IEC 60754-2; EN 50267-2-2; DIN VDE 0482-267-2-2; CEI 20-37/2-2 ; BS 6425-2*
|
|
Minimum smoke emission
|
IEC 61034-1&2; EN 61034 -1&2;DIN VDE 0482-1034-1&2; CEI 20-37/3-1&2; EN 50268-1&2*; BS 7622-1&2*
|
|
No toxic gases
|
NES 02-713; NF C 20-454
|
